y-cca

An Arm CCA Architecture with Planes feature.

🛠️ Tools

Make sure that all the following tools are installed on your local:

• python3-pyelftools, python3-venv
• acpica-tools
• openssl (debian libssl-dev)
• libglib2.0-dev, libpixman-1-dev
• dtc (debian device-tree-compiler)
• flex, bison
• make, cmake, ninja (debian ninja-build), curl, rsync
• tmux
• aarch64 crossing-compilers

📌 Install

❗ Make sure you have at least 40G of disk space. After the compilation is complete, 25G of disk space will be consumed.

The deployment architecture is shown as the following figure:

First, clone this repository to your local:

git clone https://github.com/YEWPO/y-cca.git

All dependencies list in scripts/init.sh, you can edit it when necessary.

Download dependencies by execute:

make init

Build all dependencies by execute (If you modified the codes, re-run this command is necessary):

make build

By default, the RMM version is v1.0. To build RMM v1.1, execute:

make build RMM_V1_1=ON

🚀 Launching System and Realm Guest

Run the CCA system by execute:

make run

We created scripts for QEMU and LKVM to launch Realm Guest, you can use it to launch guest.

Launching Realm Guest by QEMU (❗ Do not support Planes Feature currently):

/mnt/scripts/qemu_realm.sh

Launching Realm Guest by LKVM:

/mnt/scripts/lkvm_realm.sh

In order to debug the exception simply, you can modify the lkvm_realm.sh script to change the -c 2 to -c 1.

🔗 Code Base

• Our RMM based on Linaro RMM, branch cca/v4.
• Our Linux based on Linaro linux-cca, branch cca-full/v5+v7.
